FLOORPLAN
Mercury10 10ft Teardrop Camper Caravan
10ft Teardrop Camper Caravan For Sale
*The product images shown are for illustration purposes only and may not be an exact representation of the product. Century Camper Trailer PTY LTD reserves the right to change product specifications at any time without notice. All images used on this website are copyrighted. All rights reserved
*subject to availability
$30,000.00
*Deposit payment not apply to finance customers.
- FLOORPLAN
- SPECIFICATIONS OVERVIEW
- EXTERIOR
- TECHNICAL
- STORAGE
- CAMPING COMFORT
- ELECTRICAL SYSTEM
- Brochure
- Description
SPECIFICATIONS OVERVIEW
| Exterior Length (mm) | 4360 | ||||
| Exterior Width (mm) | 2150 | ||||
| Exterior Height (mm) | 2100 | ||||
| Occupants Capacity | 1 |
EXTERIOR
| Type | sandwich panel Vacuum made RV |
| Drawbar | 70x50x3mm main frames Hot dip galvanized chassis and drawbar |
| Chassis | 70x50x3mm main frames Hot dip galvanized chassis and drawbar |
| Hitch | ADR AS41773 Compliant |
| ADR Compliant Safety Chain | Yes |
| Suspension | AL-KO 1.5T electric brake torsion axle |
| Brakes | Australian standard 3.5T 50mm steel coupler with hand brake |
| Tyres | Goodride SL305 |
| Wheels | Heavy duty 165R13LT tires with alloy rims and spare wheel under chassis (steel rim) |
| Spare Wheel | Yes, located under van |
| Jockey wheel | 8″ Standard jocky Wheel |
| Stabilizer Legs | 4pcs high quality stabilzer legs at front & rear-under chassis |
| Ventilation | Ranger vented Roof Hatch |
| Gas Bottle Holder | 9 KG Gas Bottle Holder Ring. |
TECHNICAL
| Drawbar | 70x50x3mm main frames Hot dip galvanized chassis and drawbar |
| Chassis | 70x50x3mm main frames Hot dip galvanized chassis and drawbar |
| Frame | Fully Welded and Hot Dip Galvanised |
| Insulation | XPS Foam Core Sandwich panel |
| Exterior | Fibreglass |
| Suspension | AL-KO 1.5T electric brake torsion axle |
| Brakes | Al-KO 10″ Electric Brake Hubs |
| Jockey Wheel | 8″ Standard Jockey Wheel |
| Hitch | 3500kg ADR compliant 50mm Ball |
| Ensuite | External Shower (pop up tent optional) |
| Tare | 805kg |
| ATM | 1500kg |
| Ball Weight | 65kg |
STORAGE
| Front Storage Boot | 470mm Deep X 820mm Wide X 520mm High (Houses 9KG Gas Bottle Holder) |
| Internal Under Seat Storage | Yes (houses underbench Air-Con, Battery/Electrics, Hot water System and Water Tank. |
| Internal Utility Draws | 2X Drawers in External Kitchen |
| Internal Utility Cupboard | 4 Internal Cupboards + 2 in External Kitchen |
CAMPING COMFORT
| Internal Kitchen | N/A |
| Microwave oven | N/A |
| Fridge | Space for 60L Fridge in External Kitchen Area |
| Water Tank | 70L water tank |
| Water pump | 12V electric pump |
| Hot water system | 10L electric water heater 12V/240V |
| Main bed | Sofa + lift table can be turned into a (approxinmate) Queen size bed |
| Lounge | RV light plywood furniture/fabric U-shape sofa |
| Table | Fold down/up table for bed |
| TV System | 24″ TV Standard |
| Media Player | MP3 player with Bluetooth radio |
| Stereo System | 5inch speakers x 2pcs |
| Lights | 12V LED inner roof spotlights x 4pcs |
| Ensuite | External Shower (pop up tent optional |
| Toilet | portable toilet optional |
| Awning | Optional |
ELECTRICAL SYSTEM
| 12V Power System | 12V/100AH battery | 30A charger |
| Battery Management System | 8-way 12V control box with fuses |
| 240V Power Input | 240/220V power inlet system |
| Double Pole 240V sockets | 4 X internal + 4 X External |
| 12V Cigi Socket Internal | 1 X USB and HDMI internal + 1 X Cigi Socket External |
| USB Port Internal | 1 X USB integrated into radio plus one for tv |
| LED Lighting | Rear caravan brake lights, turning lights & reflectors with E-mark/DOT certificates; license plate lightsx2pcs |
| Air Conditioner | under Bench Air-Con/ Atwood Heater |
| External Courtesy Lights | LED outer door light x 1pcs; Rear kitchen atmosphere light x 1pcs; |
| Antenna | Optional |
| Manual Pull Out Step | N/A |
| Vent in Ensuite | External Shower Only |
| Smoke Detector | Yes |
| Solar Panel | Yes 100W |
| Fire Exstinguisher | Yes |
Brochure
The CenturyTrailers 10ft teardrop caravan is a compact and lightweight trailer designed for outdoor enthusiasts who enjoy camping and exploring the great outdoors. Measuring 10ft in length, this teardrop camper is small enough to be towed by most vehicles, making it easy to take on your next adventure.
The exterior of the caravan features a sleek and stylish design with a durable aluminum frame and reinforced fiberglass body. The caravan is also equipped with a full galley kitchen, complete with a two-burner stove, sink, and plenty of storage space for cooking supplies and food.
Inside the caravan, you’ll find a comfortable sleeping area with a queen-size bed and plenty of headroom for sitting up. The caravan also features large windows that provide ample natural light and ventilation, as well as blackout curtains for privacy and a built-in sound system for entertainment.
Additional features of the CenturyTrailers 10ft teardrop caravan include:
- 12-volt battery system for off-grid power
- 20-gallon water tank with a 12-volt water pump
- Roof vent with a fan for ventilation
- Solar panel pre-wiring for easy installation
- LED lighting throughout the interior and exterior of the caravan
- Lightweight design, weighing approximately 1,500 pounds
Overall, the CenturyTrailers 10ft teardrop caravan is a well-designed and fully equipped trailer that is perfect for adventurers who want to explore the great outdoors in comfort and style. With its compact size, durable construction, and thoughtful features, this teardrop caravan is sure to provide a comfortable and enjoyable camping experience for years to come.
*Some specifications are subject to change or may differ slightly prior to final build. If you have any enquiry or concern, feel free to contact us by phone or email, or visit our store at Rocklea.
